Single Stage Water Horizontal End Suction Centrifugal Pump Wilo Atmos GIGA-NHT

Name: Single Stage Water Horizontal End Suction Centrifugal Pump Wilo Atmos GIGA-NHT
Brand: Tianjin Shiny-Metals Technology Co., Ltd.
SKU: Wilo-Atmos GIGA-NHT
Price: 4,900.00 USD
Availability: InStock

Product Details

Place of Origin: Germany

Brand Name: WLIO

Model Number: Wilo-Atmos GIGA-NHT

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: negotiable

Packaging Details: Wooden case packing

Delivery Time: 5-8 weeks

Payment Terms: MoneyGram,Western Union,T/T,D/P,L/C,D/A

Supply Ability: Peak Season Lead Time, 1-3 months, Off Season Lead Time, one month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                Single Stage horizontal end suction centrifugal pump, Wilo horizontal end suction centrifugal pump, Wilo horizontal centrifugal water pump


Maximum Flow:	600 M³/h	Maximum Head:	120m/h
Temperature Range:	-20°C To +350°C (heat Transfer Oil), 0 To +200°C (water)	Power Supply Connection:	Three-phase 400V, 50Hz.
Protection Class:	IP55	Maximum Pressure:	25 Bar
Nominal Diameter:	DN 32 - DN 150	Impeller:	EN-GJL-250

Maximum Flow:	600 M³/h
Maximum Head:	120m/h
Temperature Range:	-20°C To +350°C (heat Transfer Oil), 0 To +200°C (water)
Power Supply Connection:	Three-phase 400V, 50Hz.
Protection Class:	IP55
Maximum Pressure:	25 Bar
Nominal Diameter:	DN 32 - DN 150
Impeller:	EN-GJL-250

Single Stage Water Horizontal End Suction Centrifugal Pump Wilo Atmos GIGA-NHT

Wilo-Atmos GIGA-NHT Single stage low pressure centrifugal pump

The dedicated pump for district heating and industrial heat supply applications.

Product Overview: It is suitable for district heating and industrial heating, and is a universal standard pump for transporting hot media. It adopts standardized dimensions, a combination of various motors, impellers, and mechanical seals. The heat-resistant and pressure-resistant structure is reliable. It is designed for continuous operation and features low life cycle cost and high overall efficiency. Energy consumption can be further reduced through the Wilo-EFC. Wilo also provides services from commissioning to maintenance and a comprehensive service package to ensure operational reliability.

Your advantages

> Universally usable thanks to standardised dimensions, a range of motor options and impellers as well as mechanical seals adapted to the type of fluid
> High reliability through heat-resistant ductile cast-iron casing, large-volume sealing chamber and pressure resistant flange (PN 25)
> High overall efficiency through improved hydraulics with MEI > 0.4; the use of IE3/IE4 motors enables high energy savings
> Self-cooling mechanical seal instead of additional cooling systems allows for an easy installation
> User-friendly spacer coupling in back pull-out design for easy maintenance
> Self-cooling technology instead of a cooling system with additional water consumption provides high sustainability
> Optional: Wilo-EFC for easy operation and further energy savings

Environmentally friendly features

High overall efficiency and high energy savings by using an IE3/IE4 motor
Energy and material savings as a result of self-cooling technology instead of a cooling system with additional water consumption
Recyclability and durability of material composition, e.g. cast iron
Design

Single-stage, low-pressure centrifugal pump with axial suction, mounted on a baseplate. Standard version with spacer coupling.
Application
- > Hot-water heating systems
- > Cooling and chilled water circulation systems
- > District heating loops up to 200 °C
- > Industrial water cycles up to 200 °C
- > Industrial heat transfer oil circuit systems up to 350 °C
Equipment/function

Single-stage low-pressure centrifugal pump in a norm pump design with coupling, coupling guard, motor and baseplate. The pump is sealed with a mechanical seal.

Typekey

Example:	Atmos GIGA-NHT 40/200-11/2
Atmos	Product family
GIGA	Series designation
NHT	Design
	NHT = standard pump for high-temperature applications
40	DN for the discharge flange
200	Impeller nominal diameter [mm]
11	Rated power P2 [kW]
2	Number of poles

Technical data
- > Permissible temperature range:
  - > -20 °C … +350 °C (heat carrier oil)
  - > 0 … +200 °C (water)
- > Mains connection 3~400 V, 50 Hz
- > Protection class IP55
- > Nominal diameter DN 32 to DN 150
- > Max. operating pressure 25 bar
Materials
- > Pump housing and lantern. Standard: EN-GJS-400-15
- > Impeller: EN-GJL-250
- > Shaft: 1.4021
- > Mechanical seal:
  - > AQ7EGG (water)
  - > AQ1VGG (heat carrier oil)
Construction
- > Single-stage low-pressure centrifugal pump as baseplate pump with axial suction ports with flanged bearing brackets and axle fastening for flexibly coupled drives
- > Spacer coupling (sleeve coupling) is standard; this provides the option of leaving the motor in position when dismantling the rotor unit
Scope of delivery
- Pump
- > Installation and operating instructions
- > Bare shaft pump or
- > Pump on baseplate with coupling and coupling guard, without motor or
- > Completely mounted pump on baseplate with electric motor
