Grundfos Cr 15-17 Vertical Multistage Stainless Steel Centrifugal Pump

Products

Grundfos Cr 15-17 Vertical Multistage Stainless Steel Centrifugal Pump

MOQ:	1
Price:	Negotiable
Standard Packaging:	Wooden Box
Delivery Period:	within 15 workdays
Payment Method:	L/C,D/A,D/P,MoneyGram,Western Union,T/T,Western Union
Supply Capacity:	Peak Season Lead Time: 1-3 months Off Season Lead Time: 1-3 months

Detail Information

Product Description

Detail Information

Brand Name

Grundfos

Model Number

CR 15-17 A-F-A-E-HQQE

Liquid Temperature Range:

-20 .. 120 °c

Liquid Conveyed:

Water

Liquid Temperature During Operation:

20 °c

Rated Flow Rate:

17 M³/H

Rated Head:

191.9m

Maximum Ambient Temperature:

60 °c

Power Supply Frequency:

50 Hz

Rated Voltage:

3 X 380-415D/660-690y V

Net Weight:

174 Kg

Gross Weight:

205kg

Highlight:

Electronically Wilo Recirculating Pump

Twin Head Wilo Recirculating Pump

Recirculating 3 hp centrifugal pump

Product Description

CR 15-17 A-F-A-E-HQQE

Vertical multistage centrifugal pump with inlet and outlet on the same horizontal plane (in-line). The pump head and base are made of cast iron, while all other liquid-contact components are manufactured from stainless steel. The cartridge-type shaft seal enhances the machine's reliability and operational safety, making maintenance more straightforward. Electrical energy is transmitted via a split coupling. Pipe connections are achieved through DIN flanges. The pump is equipped with a three-phase asynchronous motor featuring a cooling fan and a foot bracket.

Grundfos Cr 15-17 Vertical Multistage Stainless Steel Centrifugal Pump 0

Grundfos Cr 15-17 Vertical Multistage Stainless Steel Centrifugal Pump 1

CR 15-17 A-F-A-E-HQQE
Number: 98675602

Applications:

Commercial heating
Commercial air conditioning
Commercial water pressure boosting
District heating
District cooling
Machining
Industrial cleaning processes
Process water distribution
Heating supply
Refrigeration
Industrial water supply and transportation
Industrial wastewater
Process water treatment
Desalination
Surface water intake
Drinking water treatment
Municipal water transmission and distribution
Irrigation
Solar water solutions
Community and building water supply

Vertical multistage centrifugal pump

Liquid:

Liquid conveyed: Water
Liquid temperature range: -20 .. 120 °C
Liquid temperature during operation: 20 °C
Density: 998.2 kg/m³

Technical Data:

Pump speed basis: 2923 rpm
Rated flow rate: 17 m³/h
Rated head: 191.9 m
Pump orientation: Vertical
Shaft seal configuration: Single
Main shaft seal: HQQE
Shaft seal code: HQQE
Approvals: CE, EAC, UKCA, SEPRO
Drinking water certifications: WRAS, ACS
Curve tolerance: ISO9906:2012 3B

Materials:

Base: Cast iron
- Base standards: EN 1561 EN-GJL-200 / ASTM A48-25B
Impeller: Stainless steel
- Impeller material: EN 1.4301 / AISI 304
Bearings: SIC

Installation:

Maximum ambient temperature: 60 °C
Maximum operating pressure: 25 bar
Maximum pressure at specified temperatures:
- 25 bar / 120 °C
- 25 bar / -20 °C
Connection types: DIN
Inlet size: DN 50
Outlet size: DN 50
Pressure rating for pipe connection: PN 25
Motor flange size: FF300

Electrical Data:

Motor standard: IEC
Motor model: 160MD
Rated power - P2: 15 kW
Pump required power (P2): 15 kW
Power supply frequency: 50 Hz
Rated voltage: 3 x 380-415D/660-690Y V
Rated current: 28.0-26.0/16.2-15.6 A
Starting current: 660-780 %
Cos phi - Power factor: 0.89-0.87
Rated speed: 2930-2950 rpm
IE efficiency class: IE3
Motor full-load efficiency: 91.9 %
Motor efficiency at 3/4 load: 92.4-92.7 %
Motor efficiency at 1/2 load: 92.4-92.3 %
Motor pole count: 2
Enclosure rating (IEC 34-5): 55 Dust/Jetting
Insulation class (IEC 85): F
Motor number: 85U16526

Controller:

Frequency converter: None

Other:

Junction box position: 6
Minimum Efficiency Index, MEI ≥: 0.70
Net weight: 174 kg
Gross weight: 205 kg
Transport volume: 0.619 m³

Grundfos Cr 15-17 Vertical Multistage Stainless Steel Centrifugal Pump 3

Grundfos Cr 15-17 Vertical Multistage Stainless Steel Centrifugal Pump 4

Grundfos Cr 15-17 Vertical Multistage Stainless Steel Centrifugal Pump 5

Grundfos Cr 15-17 Vertical Multistage Stainless Steel Centrifugal Pump 6

Grundfos Cr 15-17 Vertical Multistage Stainless Steel Centrifugal Pump 7
