Grundfos Cr 32-14-2 Vertical Multistage Centrifugal Pump for Commercial Water Pressure Boosting

Products

Grundfos Cr 32-14-2 Vertical Multistage Centrifugal Pump for Commercial Water Pressure Boosting

MOQ:	1
Price:	Negotiable
Standard Packaging:	Standard Export Plywood Case or Carton
Delivery Period:	5-8 weeks
Payment Method:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Capacity:	Peak Season Lead Time: 1-3 months ，Off Season Lead Time: 1 month

Detail Information

Product Description

Detail Information

Brand Name

Grundfos

Model Number

CR 32-14-2 A-F-A-E-HQQE

Liquid Temperature Range:

-30 .. 120 °c

Liquid Conveyed:

Water

Liquid Temperature During Operation:

20 °c

Rated Flow Rate:

30 M³/H

Rated Head:

Maximum Ambient Temperature:

55 °c

Power Supply Frequency:

50 Hz

Rated Voltage:

3 X 380d/660y V

Net Weight:

346 Kg

Gross Weight:

466 Kg

Highlight:

IP44 Wilo Recirculating Pump

Self Priming Wilo Recirculating Pump

Wilo Self priming centrifugal pumps

Product Description

CR 32-14-2 A-F-A-E-HQQE
Vertical multistage centrifugal pump with inlet and outlet on the same horizontal plane (in-line). The pump head and base are made of cast iron, while all other liquid-contact components are manufactured from stainless steel. The cartridge-type shaft seal enhances the machine's reliability and operational safety, making maintenance more straightforward. Electrical energy is transmitted via a split coupling. Pipe connections are achieved through DIN flanges. The pump is equipped with a three-phase asynchronous motor featuring a cooling fan and a foot bracket.

Grundfos Cr 32-14-2 Vertical Multistage Centrifugal Pump for Commercial Water Pressure Boosting 0

Grundfos Cr 32-14-2 Vertical Multistage Centrifugal Pump for Commercial Water Pressure Boosting 1

CR 32-14-2 A-F-A-E-HQQE
Number: 98704370
Applications:

Commercial heating
Commercial air conditioning
Commercial water pressure boosting
District heating
District cooling
Machining
Industrial cleaning processes
Process water distribution
Heating supply
Refrigeration
Industrial water supply and transportation
Industrial wastewater
Process water treatment
Desalination
Surface water intake
Drinking water treatment
Municipal water transmission and distribution
Irrigation
Solar water solutions
Community and building water supply
Vertical multistage centrifugal pump

Liquid:

Liquid conveyed: Water
Liquid temperature range: -30 .. 120 °C
Liquid temperature during operation: 20 °C
Density: 998.2 kg/m³

Technical Data:

Pump speed basis: 2951 rpm
Rated flow rate: 30 m³/h
Rated head: 212 m
Pump orientation: Vertical
Shaft seal configuration: Single
Main shaft seal: HQQE
Shaft seal code: HQQE
Approvals: CE, EAC, UKCA, SEPRO
Drinking water certifications: WRAS, ACS
Curve tolerance: ISO9906:2012 3B

Materials:

Base: Cast iron
- Base standards: EN 1563 EN-GJS-500-7 / ASTM A536 80-55-06
Impeller: Stainless steel
- Impeller material: EN 1.4301 / AISI 304
Bearings: SIC
Support bearings: Graflon

Installation:

Maximum ambient temperature: 55 °C
Maximum operating pressure: 30 bar
Maximum pressure at specified temperatures:
- 30 bar / 120 °C
- 30 bar / -30 °C
Connection types: DIN
Inlet size: DN 65
Outlet size: DN 65
Pressure rating for pipe connection: PN 40
Motor flange size: FF350

Electrical Data:

Motor standard: IEC
Motor model: INNOMOTICS
Rated power - P2: 30 kW
Pump required power (P2): 30 kW
Power supply frequency: 50 Hz
Rated voltage: 3 x 380D/660Y V
Rated current: 55.0/31.5 A
Starting current: 780 %
Cos phi - Power factor: 0.89
Rated speed: 2955 rpm
Efficiency: IE3 93.3%
IE efficiency class: IE3
Motor full-load efficiency: 93.3 %
Motor efficiency at 3/4 load: 93.4 %
Motor efficiency at 1/2 load: 92.6 %
Motor pole count: 2
Enclosure rating (IEC 34-5): IP55
Insulation class (IEC 85): F
Motor number: M1U05332

Controller:

Frequency converter: None

Other:

Junction box position: 6
Minimum Efficiency Index, MEI ≥: 0.70
Net weight: 346 kg
Gross weight: 466 kg
Transport volume: 0.001 m³

Grundfos Cr 32-14-2 Vertical Multistage Centrifugal Pump for Commercial Water Pressure Boosting 3

Grundfos Cr 32-14-2 Vertical Multistage Centrifugal Pump for Commercial Water Pressure Boosting 4

Grundfos Cr 32-14-2 Vertical Multistage Centrifugal Pump for Commercial Water Pressure Boosting 5

Grundfos Cr 32-14-2 Vertical Multistage Centrifugal Pump for Commercial Water Pressure Boosting 6
