1 Inch Cast Iron Agricultural Drainage Pumps Wilo Drain VC Vertical Pedestal Type

Wilo-Drain VC Long Lasting Drainage Pump for Wastewater with Adjustable Float Switch and High Temperature Fluids Vertical Pedestal-Type Drainage Pump for Wastewater Applications

Your advantages For fluid temperatures up to 95 °C Long service life, even in the event of long periods of standstill Easy operation due to the attached float switch

Design Vertical pedestal-type non-submersible drainage pump with standard motor Application Pumping of Wastewater with a maximum fluid temperature of 95 °C Equipment/function A float switch is fitted which has adjustable switching points

Typekey Technical data Mains connection: 1~230 V, 50 Hz or 3~400 V, 50 Hz Fluid temperature: 3 ... 95 °C Operating mode: S3 25% Pressure port: VC 32: R 1 VC 40: R 1½ Protection class: IP54 Materials VC 32 Motor housing: Al Pump housing: EN-GJL-250 Impeller: 1.4028 Shaft: Stainless steel Float: PP VC 40 Motor housing: Al Pump housing: EN-GJL-250 Impeller: EN-GJL-250 Shaft: Stainless steel Float: PP Construction Vertical pedestal-type centrifugal pump equipped with a float switch for stationary installation. Single-stage hydraulics with semi-open, multi-channel impeller and horizontal pressure port. An inlet filter is integrated into the suction area of the hydraulics. Drive is provided by a standard motor. Hydraulics and motor are rigidly connected via the pump shaft (in the shaft protection pipe). The pump shaft is located by a plain bearing and the plain bearing is lubricated by the fluid. A float switch is fitted for automatic operation. Switching points can be set using stops. Scope of delivery Pump with fitted float switch Installation and operating instructions Accessories Connection cable Motor protection plug Connection cable kit: 5 m connection cable Motor protection plug
