Hrb6-0.6~5.5 Precision Gear Pump for Spinning & Industrial Metering

MOQ:	1
Precio:	Negociable
Embalaje Estándar:	Estuche de madera contrachapada de exportación estándar o cartón
Período De Entrega:	5-8 semanas
Método De Pago:	LC, D/A, D/P, T/T, Unión Occidental
Capacidad De Suministro:	Tiempo de entrega en temporada alta: 1-3 meses; Tiempo de entrega fuera de temporada: 1 mes

Información detallada

Descripción de producto

Información detallada

Nombre de la marca

Número de modelo

HRB6-2.4

Desplazamiento por salida:

2,4 cc/r

Tornillo de montaje:

Presión máxima de entrada:

≤20 MPa

Presión máxima de salida:

≤ 40 Mpa

Rango de velocidades de trabajo:

5~40 rpm

Especificación:

134,8x100x100mm

Forma:

1 entrada, 10 salidas

Presión de trabajo:

Entrada: ≤20MPa; Salida: ≤40MPa

Temperatura de trabajo:

≤320 ℃

Viscosidad del fluido de hilatura:

≤4000 equilibrio

Resaltar:

precision gear metering pump

industrial spinning gear pump

HRB6 metering pump with warranty

Descripción de producto

HRB6 Series Precision Spinning Gear Pump

The HRB6 Series Precision Spinning Gear Pump is a high-precision metering and conveying device specifically engineered for chemical fiber spinning processes. This industrial-grade pump delivers exceptional performance across chemical, chemical fiber, food, biological, and pharmaceutical industries.

Product Specifications

Parameter	Specification
Model	HRB6-2.4
Displacement	2.4 cc/rev
Dimension A	92.8 mm
Overall Length	134.8 mm
Overall Width	100 mm
Overall Height	100 mm
Mounting Screw	M12
Structure	1 Inlet 10 Outlets
Max Inlet Pressure	≤20 MPa
Max Outlet Pressure	≤40 MPa
Max Working Temperature	≤320ºC
Applicable Viscosity	≤4000 POISE
Working Speed	5~40 rpm

Main Applications

Polyester/Nylon filament spinning production lines for stable melt metering and conveying
Spinning processes for specialty fibers including polypropylene, spandex, and aramid
Production of non-woven materials such as non-woven fabrics and acetate fibers
Metering and conveying of high-viscosity fluids in chemical and pharmaceutical industries

Product Advantages

High Metering Accuracy: Gear pump structure ensures stable and precise melt delivery, guaranteeing uniform flow during spinning and improving linear density consistency in finished fibers
Wide Operating Range: Withstands outlet pressures up to 40MPa and temperatures up to 320ºC, compatible with high-viscosity spinning fluids for various process requirements
Multi-Outlet Design: 1-inlet-10-outlet structure feeds multiple spinning positions simultaneously, enhancing production efficiency and reducing equipment integration costs
Standardized Installation: Complete series uses M12 mounting screws with serialized dimensions for quick adaptation and replacement with existing spinning equipment

Complete Model Series

Model	Displacement (cc/rev)	Dimension A (mm)	Dimension B (mm)	Mounting Screw
HRB6-0.6	0.6	81.0	123.0	M12
HRB6-1.2	1.2	85.2	127.2	M12
HRB6-1.4	1.4	86.6	128.6	M12
HRB6-1.6	1.6	87.8	129.8	M12
HRB6-1.8	1.8	88.7	130.7	M12
HRB6-2.4	2.4	92.8	134.8	M12
HRB6-3.0	3.0	97.1	139.1	M12
HRB6-3.6	3.6	101.3	143.3	M12
HRB6-4.0	4.0	104.1	146.1	M12
HRB6-4.5	4.5	107.6	149.6	M12
HRB6-5.0	5.0	111.1	153.3	M12
HRB6-5.5	5.5	114.6	156.6	M12

After Sales Service

Enjoy peace of mind with our comprehensive after-sales service. We offer a 7-day replacement policy and a 12-month repair service absolutely free of charge for any quality-related issues, ensuring your complete satisfaction and confidence in our products.

Company Profile

Packaging & Shipping

Standard export wooden case packaging to protect the pump from damage during transportation
Support multiple shipping methods (sea, air, express) to meet different delivery time requirements
Complete product documents (operation manual, test report, quality certificate) provided with each shipment

Frequently Asked Questions

Are you a factory?

We are based in Shanghai, China, starting from 2011. We specialize in production and sales of various industrial flow meters and related products.

What can you buy from us?

We provide one-stop flow meter services, including flow meters, liquid level gauges, vacuum gauges, pumps, sensors, industrial thermometers, and more.

What is your terms of packing?

Generally, JSN brand colorful cardboard boxes packing. OEM brand brown cardboard boxes packing available.

How about your delivery time?

Standard type: 6-7 working days after order confirmation. Non-standard type: 8-10 working days after order confirmation.

What's your MOQ?

We have no MOQ requirement - 1 piece for test purposes is acceptable.

How do you ensure good product quality?

We maintain a complete quality control system with all products fully checked by IQC and OQC departments before shipment.

How long is your quotation valid?

Our quotations are valid for 1 month.

Can you accept OEM brand?

Yes, we accept OEM branding without extra charge.

How long is your product warranty?

7 days replacement and 12 months repair free of charge for quality problems.

Can you produce according to the samples?

Yes, we can produce according to your samples or technical drawings.
